PCB Cutting Machine
Mark 5 – UV Series (Model MS0404-V-A)
This product is a professional laser cutting machine used in the PCB industry, which can be used for fine cutting of hard board, soft board, covering film, and other products. Equipped with a UV laser source, the Mark 5 delivers high precision, non-contact processing with minimal heat-affected zone – ideal for high-density PCB and FPC applications.
Technical Parameters
Advantages of FPC/PCB laser cutting:
Non-contact
- There will be no contact, no mechanical stress or deformation.
Adaptable
- Processing complex graphics, greatly shorten the delivery cycle.
- Processing graphics can be changed at will, save the cost of the mold.
High Precision
- Imported vision positioning system to meet the needs of high-precision processing.
- Equipped with UV or green laser, heat-affected-zone is small, can more effectively process high density PCB products.
Multi-Platform, Multi-Purpose Machine
Hard board transmission platform can be configured to meet the requirements of hard board processing and realize seamless docking with SMT assembly line. Optional soft board platform to meet the requirements of soft board, covering film cutting.
High Precision Working Table
High precision linear motor and marble platform are optional for high precision processing.
Software
Professional laser cutting system, easy to learn. It can apply to MES system customization and seamless connection of production line.
Vision System
High performance CCD can realize automatic location.
Optical System
The high quality laser source and optical system ensure the machine works stably in constant time. Full enclosed protection makes the operation very safe.
| Laser Power | UV laser: 10 / 15W |
| Power Supply | AC220±10 50/60Hz |
| Working Area | 400mm x 400mm |
| Beam Diameter | <20µm |
| Working Accuracy | ±20µm |
| X/Y Platform | Linear motor |
| Base | High precision marble |
| Working Environment | Temperature: 15~30°C; Relative humidity: 5~85%, no condensation, no dust or less dust |
| Cooling Way | Water |
| Graphic Format | DXF, etc. |
| Dimension (L×W×H) | 1600mm × 1200mm × 1660mm |
| No. | Item | Specification | Quantity |
|---|---|---|---|
| 1 | Laser source | UV 10 / 15W | 1 |
| 3 | Galvo head | High speed | 1 |
| 4 | Field lens | Telecentric lens | 1 |
| 5 | Platform | Marble table + linear motor | 1 |
| 6 | Computer | Industrial computer | 1 |
| 7 | Control board | – | 1 |
| 8 | CCD system | – | 1 |
| 9 | Chiller | – | 1 |
Item No. 2 is not listed in the source configuration table.
Camera Module
No stress, no contact processing, precision, high efficiency.
FPC Soft Board
Laser cutting FPC soft board, smooth edge, no burr, no need for mold.
Cover Film Window
Laser cutting precision, high efficiency, small slit, small material loss.
Soft & Hard Board / Hard Board
Smooth edge, no burr, no need for mold.
